MRCOOL® Signature Series 3 Ton 36,000 BTU 14 SEER R-410A Multi-Position Packaged Heat Pump (MPH361M414A)

A MRCOOL packaged heat pump combines high performance cooling and powerful heating in one convenient, easy-to-install system. These units are competitively priced and operate at 14 SEER efficiency. A MRCOOL packaged heat pump will be a great solution for tough air comfort problems in a suburban home, commercial office space, condominium, seaside villa, or wherever you desire. MRCOOL packaged heat pumps combine superior product quality, energy efficiency, quiet operation, and financial value. The units come standard with a high performance compressor and eco-safe, chlorine-free R-410A refrigerant. This is truly an all-in-one packaged unit that will deliver energy efficient air comfort with minimal environmental impact.

Key Features

  • Warranty is 10 years on all parts if registered, 5 years if not (no licensed tech required)
  • 14 SEER efficiency
  • Designed for easy and convenient installation
  • Optional electric heat available
  • R-410A environmentally friendly refrigerant
  • Built in short cycle protection to protect the compressor
  • One piece "no leak" top design
  • Sloped drain for improved indoor air quality
  • Louvered panel coil protection
  • Insulation to minimize heat loss plus reduce sound
  • Built in "quiet shift" operation during defrost on select models
  • Efficient constant torque motor for wide airflow range

Specifications & Dimensions

MODEL MPH361M414A
SEER
14
SEER2
13.4
EER 11
EER2 10.6
COP 47
3.5
HSPF 8
HSPF2 6.7
CFM 1250
TONNAGE 3
COOLING CAPACITY
34000
HEATING CAPACITY
32400
VOLTAGE
208/230
PHASE 1
CYCLE 60
STAGE Single
MAX FUSE BREAKER
35
MIN CIRCUIT AMPACITY
23.4
COLOR
Gray
COLOR FAMILY
Gray
RATED LOAD
14.7
MAX COVERAGE AREA
1500
REFRIGERANT TYPE
R-410A
REFRIGERANT VOLUME
90
DECIBEL RATING
76
MIN AMBIENT HEAT
0
COMPRESSOR MOTOR TYPE
Scroll
CONDENSER FAN MOTOR TYPE
ECM
CONDENSER FAN MOTOR HP
1/6
BLOWER MOTOR TYPE
ECM
BLOWER MOTOR HP
1/2
BLOWER MOTOR SPEEDS
Multi-speed
BLOWER MOTOR RPM
640-1345
FILTER TYPE
Replaceable
FILTER SIZE
14x20x1
METERING DEVICE
TXV
AUXILIARY HEATER INCLUDED
No
AUXILIARY HEATER AVAILABLE
Yes
AUXILIARY HEATER SIZES
5kw, 7.5kw, 10kw
UL RECOGNIZED No
UL LISTED
No
ETL LISTED
Yes
ETL CERTIFIED
No
LEED CERTIFIED
No
ASHRAE COMPLIANT
No
ENERGY STAR COMPLIANT
No
ENERGY STAR CERTIFIED
No
AHRI CERTIFIED
Yes
REGISTERED WARRANTY
Warranty is 10 years on all parts if registered
BASE WARRANTY
5 years if not (no licensed tech required)
HAS BATTERIES
No
CONTAINS ELECTRONICS
Yes
CONTAINS CHEMICALS
Yes
CONTAINS AEROSOL
Yes
CONTAINS COMPRESSED GAS
Yes
PROPOSITION 65 WARNING
Yes
RESTRICTED STATES
No
NET DEPTH
47.66 in
NET HEIGHT
40.89 in
NET WIDTH
47.66 in
NET WEIGHT
340
GROSS DEPTH
48
GROSS HEIGHT
42.5
GROSS WIDTH
48.75
FREIGHT CLASS
125



Information & Guides


MRCOOL® Signature Series 3 Ton 36,000 BTU 14 SEER R-410A Multi-Position Packaged Heat Pump (MPH361M414A)
